ULTRASONIC CLEANING UNIT
CLEANING OF INKTRAYS AND PAD PRINTING ACCESSORIES
The unit consists of a simple tank out of stainless steel and a basket in which the user puts the accessories to be cleaned in a flat way.
The ULTRASONIC WAVES transmitted by the generator are being sent out through the cleaning agent and produce cavitation energy which accelerates the release of dirt particles. By slightly heating the cleaning agent, the chemical reaction will be increased.
The ULTRASONIC WAVES which are radiated in the cleaning liquid guarantee this way a perfect cleaning of all the accessories, irrespective of the used ink type (one- or two-component ink) or of the drying time of the ink.
After a while (the treating time depends on the degree and the type of contamination) the accessories are cleaned.
Simply rinse the accessories afterwards with pure water in a tank or tub after the ultrasonic cleaning.
All the proposed models comes equipped with:
– Heating with thermostat 30 to 80°C
– Maximum filling level indication
– Turning knob for draining the tank
– 2 carrying handles
– Timer: up to 30 minutes or continuously
– Stainless steel basket
– Stainless steel tank and stainless steel casing
– Ultrasonic frequency 37 KHz
– Mains voltage: 220 V
